BTECH UV-50X2 (Second Gen.) Mobile 50 Watt Dual Band Base, Mobile Radio: VHF, UHF Amateur (Ham)

UV-50X2 (Second Generation) 50W Mobile Two Way Radio

The UV-50X2 is very much the same radio, our users have come to enjoy, with several new functionality improvements. The UV-50X2 has seen several performance improvements and tweaks in its second generation release.

The UV-50X2 has new menus and operations that allow audio I/O from its RJ45 microphone port. This allows the UV-50X2 to be installed for custom applications, where users want more control on where the speaker and mic audio is routed to.

The UV-50X2 (Second Generation) includes VOX support. VOX allows for handsfree use with your favorite audio accessories or the included handheld microphone.

In the Box:

• UV-50X2 Mobile Radio
• DTMF Handheld Microphone
• 6.5′ Direct Connect 12V Leads Vehicle
• Mounting Bracket Screws & Mounting Hardware
• Easy-to-read Manual (written in the US)
• RJ-45 to Kenwood K1 Accessory Adaptor

BTECH Radios are not like other similar looking radios. BTECH radios are designed in the USA with custom firmware and internal hardware differences. BTECH radios are backed with a full US support. A BTECH label means you are getting the best radio available! A few of our highlighted differences are below:

RJ45 to K1 Audio Adaptor, the UV-50X2 includes a RJ45 to K1 Audio Adaptor. K1 Audio accessories are used on our BTECH handheld radios, and now you can use those same accessories with your mobile radios! The radio includes special menus to allow audio to be routed both through the UV-50X2 and K1 accessory, only through the radio, or only through the K1 audio accessory.

Uniquely customize your UV-50X2: The X-Series Mobiles use our Multi-Color LCD display screen. You can adjust the complete display colors to be exactly as you want it. Beyond the display, you can fully customize your channels to display their alpha-numeric names or frequency settings. There are 200 programmable memory channels. You can add or remove channels from scanning list. You can easily program from a PC or right on the radio itself. Pair the UV-50X2 with the Nagoya UT-72 Magnetic Mount Antenna for easy installation with the UHF antenna connectors.

The UV-50X2 supports the most common Analog Tones. It supports CTCSS, DCS, 2Tone, 5Tone, and DTMF calling methods. Set-up your calling methods to call by group tones. Tone calling (private line) is required by most repeater applications and the UV-50X2 supports the latest standards. The UV-50X2 can even send DTMF tones. This allows for sending ANI (Caller ID) or remote commands that require DTMF tones; or it can receive incoming DTMF tones to allow for remote stun or kill commands

Quad Watch and Display Sync: The UV-50X2 operates as multiple radios in one, with either VHF or UHF as the ‘Main’ band, while simultaneously watching up to 3 other frequencies or channels; and, if you like, you can configure your UV-50X2 for simultaneous VHF-VHF or UHF-UHF operation, too! Additionally, as a new feature added: you can monitor both VFO (frequency) and channel modes simultaneously.

Dual Sync Display: With Dual Sync Display, you can synchronize channel lines to one or two channels. This allows you to sync display ‘lines’ to a single channel allowing the user to have both frequency and channel name data displayed simultaneously.

Technical Specifications

Bands Supported VHF & UHF Dual Band Radio Memory Channel 200 Channels Output power 50W/5W Tone Support CTCSS, DCS, 5TONE, 2TONE, DTMF Accessory Jack Mono Speaker Output In Rear, RJ45 Audio Output in Front, K1 Accessories support with included Adaptor Additional Features Display Sync, Nuisance Channel Scan Skip, SOS Alarm, NOAA Weather Channels, Transmit Time-Out, Busy Channel Lockout, DTMF Keypad, Adjustable Scanning Modes, Quad Watch, Adjustable Squelch Size 5.7 (w) x 1.85 (h) x 7.5 (d) in Weight 2.65lb Antenna Jack UHF (SO239 Connector)

BTECH UV-50X2 VHF/UHF Dual Band Radio

Second Generation

The UV-50X2 has been upgraded with Audio I/O support through the RJ45 Microphone Port. Included is also a K1 Audio adaptor. The K1 accessory jack is the most common radio accessory jack in the market. This means the UV-50X2 has the widest support of aftermarket audio accessories allowing you to find the best accessories for however you use your radio.

The UV-50X2 includes all of the necessary mounting hardware to easily wire into any vehicle. You can use the UV-50X2 as a base station at home or in the office with the optional RPS-30M power supply (not included).

Recommended Accessories: Pair UV-50X2 with the Nagoya UT-72 Magnetic Mount Antenna for easy installation. The PC04 FTDI Cable is recommended for easy computer programming
The UV-50X2 operates as multiple radios in one, with either 144 MHz or 430 MHz as the “Main” TX/RX band, while simultaneously watching up to 3 other frequencies or channels; and, if you like, you can configure your UV-50X2 for simultaneous VHF-VHF or UHF-UHF operation, too!

Kit Includes: BTECH UV-50X2, RJ45 to K1 Audio Adaptor, Speaker Mic, DC Cable, Radio & Mic Brackets, Mounting Hardware, and User Guide
